Autocad Shortcuts

Autocad is a CAD software which is primarily used for 2D drafting of various engineering drawings like plot plan, equipment layout, piping layout etc. in oil and gas industry. It is also used for 3D modelling in other industries. Here is a list of shortcuts to help you improve your productivity on Autocad.

Manage Drawings

Sr.NumberTitle
1Ctrl+nNew Drawing
2Ctrl+sSave drawing
3Ctrl+oOpen drawing
4Ctrl+pPlot dialog box
5Ctrl+Tab/Ctrl+Shift+TabSwitch to next / switch to previous drawing
6Ctrl+Page Up/Page DownSwitch to next tab / switch to previous tab in current drawing
7Ctrl+qExit
8Ctrl+aSelect all objects

Toggle Drawing Modes

Sr.NumberTitle
9F3Toggles object snap mode
10F7Toggle grid mode
11F8Toggle ortho mode
12F9Toggle snap mode
13F10Toggle polar mode
14F11Toggle object snap tracking
15F12Toggle dynamic input mode

Manage Screen

Sr.NumberTitle
16Ctrl+0 (zero)Clean Screen
17Ctrl+1Property Palette
18Ctrl+2Design Center Palette
19Ctrl+3Tool Palette
20Ctrl+4Sheet Set Palette
21Ctrl+6DBConnect Manager
22Ctrl+7Markup Set Manager Palette
23Ctrl+8Quick Calc
24Ctrl+9Command Line

Manage Workflow

Sr.NumberTitle
25Ctrl+cCopy object
26Ctrl+xCut object
27Ctrl+vPaste object
28Ctrl+Shift+cCopy to clipboard with base point
29Ctrl+Shift+vPaste data as block
30Ctrl+zUndo last action
31Ctrl+yRedo last action
32Ctrl+[Cancel current command (or ctrl+\)

Toggle General Features

Sr.NumberTitle
33Ctrl+dToggle coordinate display
34Ctrl+gToggle Grid
35Ctrl+eCycle isometric planes
36Ctrl+fToggle running object snaps
37Ctrl+hToggle Pick Style
38Ctrl+Shift+hToggle Hide pallets
39Ctrl+iToggle Coords
40Ctrl+Shift+iToggle Infer Constraints

3D Command Shortcuts

Sr.NumberTitle
413A3DARRAY / Creates a 3D matrix of objects in a rectangular or polar arrangement.
423D03DORBIT/ Rotates the view in 3D space, but constrained to horizontal and vertical orbit only.
433DW3DWALK/ Changes the 3D view in a drawing interactively to create the appearance of walking through the model.
443F3DFACE/ Creates a three-sided or four-sided surface in 3D space.
453M3DMOVE/ In a 3D view, displays the 3D Move gizmo to aid in moving 3D objects a specified distance in a specified direction.
463P3DPOLY/ Creates a 3D polyline.
473R3DROTATE/ In a 3D view, displays the 3D Rotate gizmo to aid in revolving 3D objects around a base point.
483S3DSCALE/ In a 3D view, displays the 3D Scale gizmo to aid in resizing 3D objects.

Command Shortcuts -A

Sr.NumberTitle
49AARC / Creates an arc.
50ADCADCENTER / Manages and inserts content such as blocks, xrefs, and hatch patterns.
51AAAREA / Calculates the area and perimeter of objects or of defined areas.
52ALALIGN / Aligns objects with other objects in 2D and 3D
53APAPPLOAD / Load Application
54ARARRAY / Creates multiple copies of objects in a pattern.
55ARRACTRECORD / Starts the Action Recorder.
56ARMACTUSERMESSAGE / Inserts a user message into an action macro.
57ARUACTUSERINPUT / Pauses for user input in an action macro.
58ARSACTSTOP / Stops the Action Recorder and provides the option of saving the recorded actions to an action macro file.
59ATIATTIPEDIT / Changes the textual content of an attribute within a block.
60ATTATTDEF / Redefines a block and updates associated attributes.
61ATEATTEDIT / Changes attribute information in a block.

Command Shortcuts -B

Sr.NumberTitle
62BBLOCK / Creates a block definition from selected objects.
63BCBCLOSE / Closes the Block Editor.
64BEBEDIT / Opens the block definition in the Block Editor.
65BHHATCH / Fills an enclosed area or selected objects with a hatch pattern, solid fill, or gradient fill.
66BOBOUNDARY / Creates a region or a polyline from an enclosed area.
67BRBREAK / Breaks the selected object between two points.
68BSBSAVE / Saves the current block definition.
69BVSBVSTATE / Creates, sets, or deletes a visibility state in a dynamic block.

Command Shortcuts -C

Sr.NumberTitle
70CCIRCLE / Creates a circle.
71CAMCAMERA / Sets a camera and target location to create and save a 3D perspective view of objects.
72CBARCONSTRAINTBAR / A toolbar-like UI element that displays the available geometric constraints on an object.
73CHPROPERTIES / Controls properties of existing objects.
74CHACHAMFER / Bevels the edges of objects.
75CHKCHECKSTANDARDS / Checks the current drawing for standards violations.
76CLICOMMANDLINE / Displays the Command Line window.
77COLCOLOR / Sets the color for new objects.
78COCOPY / Copies objects a specified distance in a specified direction.
79CTCTABLESTYLE / Sets the name of the current table style
80CUBENAVVCUBE / Controls the visibility and display properties of the ViewCube tool.
81CYLCYLINDER / Creates a 3D solid cylinder.

Command Shortcuts -D

Sr.NumberTitle
82DDIMSTYLE / Creates and modifies dimension styles.
83DANDIMANGULAR / Creates an angular dimension.
84DARDIMARC / Creates an arc length dimension.
85JOGDIMJOGGED / Creates jogged dimensions for circles and arcs.
86DBADIMBASELINE / Creates a linear, angular, or ordinate dimension from the baseline of the previous or selected dimension.
87DBCDBCONNECT / Provides an interface to external database tables.
88DCEDIMCENTER / Creates the center mark or the centerlines of circles and arcs.
89DCODIMCONTINUE / Creates a dimension that starts from an extension line of a previously created dimension.
90DCONDIMCONSTRAINT / Applies dimensional constraints to selected objects or points on objects.
91DDADIMDISASSOCIATE / Removes associativity from selected dimensions.
92DDIDIMDIAMETER / Creates a diameter dimension for a circle or an arc.
93DEDDIMEDIT / Edits dimension text and extension lines.
94DIDIST / Measures the distance and angle between two points.
95DIVDIVIDE / Creates evenly spaced point objects or blocks along the length or perimeter of an object.
96DJLDIMJOGLINE / Adds or removes a jog line on a linear or aligned dimension.
97DJODIMJOGGED / Creates jogged dimensions for circles and arcs.
98DLDATALINK / The Data Link dialog box is displayed.
99DLUDATALINKUPDATE / Updates data to or from an established external data link.
100DODONUT / Creates a filled circle or a wide ring.
101DORDIMORDINATE / Creates ordinate dimensions.
102DOVDIMOVERRIDE / Controls overrides of system variables used in selected dimensions.
103DRDRAWORDER / Changes the draw order of images and other objects.
104DRADIMRADIUS / Creates a radius dimension for a circle or an arc.
105DREDIMREASSOCIATE / Associates or re-associates selected dimensions to objects or points on objects.
106DRMDRAWINGRECOVERY / Displays a list of drawing files that can be recovered after a program or system failure.
107DSDSETTINGS / Sets grid and snap, polar and object snap tracking, object snap modes, Dynamic Input, and Quick Properties.
108DTTEXT / Creates a single-line text object.
109DVDVIEW / Defines parallel projection or perspective views by using a camera and target.
110DXDATAEXTRACTION / Extracts drawing data and merges data from an external source to a data extraction table or external file

Command Shortcuts -E

Sr.NumberTitle
111EERASE / Removes objects from a drawing.
112EDDDEDIT / Edits single-line text, dimension text, attribute definitions, and feature control frames.
113ELELLIPSE / Creates an ellipse or an elliptical arc.
114EREXTERNALREFERENCES / Opens the External References palette.
115EXEXTEND / Extends objects to meet the edges of other objects.
116EXITQUIT / Exits the program.
117EXPEXPORT / Saves the objects in a drawing to a different file format.
118EXTEXTRUDE / Extends the dimensions of a 2D object or 3D face into 3D space.

Command Shortcuts -F

Sr.NumberTitle
119FFILLET / Rounds and fillets the edges of objects.
120FIFILTER / Creates a list of requirements that an object must meet to be included in a selection set.
121FSHOTFLATSHOT / Creates a 2D representation of all 3D objects based on the current view.

Command Shortcuts -G

Sr.NumberTitle
122GGROUP / Creates and manages saved sets of objects called groups.
123GCONGEOCONSTRAINT / Applies or persists geometric relationships between objects or points on objects.
124GDGRADIENT / Fills an enclosed area or selected objects with a gradient fill.
125GEOGEOGRAPHICLOCATION / Specifies the geographic location information for a drawing file.

Command Shortcuts -H

Sr.NumberTitle
126HHATCH / Fills an enclosed area or selected objects with a hatch pattern, solid fill, or gradient fill.
127HEHATCHEDIT / Modifies an existing hatch or fill.
128HIHIDE / Regenerates a 3D wireframe model with hidden lines suppressed.

Command Shortcuts – I

Sr.NumberTitle
129IINSERT / Inserts a block or drawing into the current drawing.
130IADIMAGEADJUST / Controls the image display of the brightness, contrast, and fade values of images.
131IATIMAGEATTACH / Inserts a reference to an image file.
132ICLIMAGECLIP / Crops the display of a selected image to a specified boundary.
133IMIMAGE / Displays the External References palette.
134IMPIMPORT / Imports files of different formats into the current drawing.
135ININTERSECT / Creates a 3D solid, surface, or 2D region from overlapping solids, surfaces, or regions.
136INFINTERFERE / Creates a temporary 3D solid from the interferences between two sets of selected 3D solids.
137IOINSERTOBJ / Inserts a linked or embedded object.

Command Shortcuts – J

Sr.NumberTitle
138JJOIN / Joins similar objects to form a single, unbroken object.

Command Shortcuts – L

Sr.NumberTitle
139LLINE / Creates straight line segments.
140LALAYER / Manages layers and layer properties.
141LASLAYERSTATE / Saves, restores, and manages named layer states.
142LEQLEADER / Creates a leader and leader annotation.
143LENLENGTHEN / Changes the length of objects and the included angle of arcs.
144LESSMESHSMOOTHLESS / Decreases the level of smoothness for mesh objects by one level.
145LILIST / Displays property data for selected objects.
146LOLAYOUT / Creates and modifies drawing layout tabs.
147LTLINETYPE / Loads, sets, and modifies linetypes.
148LTSLTSCALE / Changes the scale factor of linetypes for all objects in a drawing.
149LWLWEIGHT / Sets the current lineweight, lineweight display options, and lineweight units.

Command Shortcuts – M

Sr.NumberTitle
150MMOVE / Moves objects a specified distance in a specified direction.
151MAMATCHPROP / Applies the properties of a selected object to other objects.
152MATMATERIALS / Shows or hides the Materials window.
153MEMEASURE / Creates point objects or blocks at measured intervals along the length or perimeter of an object.
154MEAMEASUREREGION / Measures the distance, radius, angle, area, and volume of selected objects or sequence of points.
155MIMIRROR / Creates a mirrored copy of selected objects.
156MLMLNE / Creates multiple parallel lines.
157MLAMLEADERALIGN / Aligns and spaces selected multileader objects.
158MLCMLEADERCOLLECT / Organizes selected multileaders that contain blocks into rows or columns, and displays the result with a single leader.
159MLDMLEADER / Creates a multileader object.
160MLEMLEADEREDIT / Adds leader lines to, or removes leader lines from, a multileader object.
161MLSMLEADERSTYLE / Creates and modifies multileader styles.
162MOPROPERTIES / Controls properties of existing objects.
163MOREMESHSMOOTHMORE / Increases the level of smoothness for mesh objects by one level.
164MSMSPACE / Switches from paper space to a model space viewport.
165MSMMARKUP / Opens the Markup Set Manager.
166MTMTEXT / Creates a multiline text object.
167MVMVIEW / Creates and controls layout viewports.

Command Shortcuts – N

Sr.NumberTitle
168NORTHGEOGRAPHICLOCATION / Specifies the geographic location information for a drawing file.
169NSHOTNEWSHOT / Creates a named view with motion that is played back when viewed with ShowMotion.
170NVIEWNEWVIEW / Creates a named view with no motion.

Command Shortcuts – O

Sr.NumberTitle
171OOFFSET / Creates concentric circles, parallel lines, and parallel curves.
172OPOPTIONS / Customizes the program settings.
173ORBIT3DORBIT / Rotates the view in 3D space, but constrained to horizontal and vertical orbit only.
174OSOSNAP / Sets running object snap modes.

Command Shortcuts – P

Sr.NumberTitle
175PPAN / Adds a parameter with grips to a dynamic block definition.
176PAPASTESPEC / Pastes objects from the Clipboard into the current drawing and controls the format of the data.
177PARPARAMETERS / Controls the associative parameters used in the drawing.
178PARAMBPARAMETER / Adds a parameter with grips to a dynamic block definition.
179PATCHSURFPATCH /
180PCPOINTCLOUD /
181PCATTACHPOINTCLOUDATTACH /
182PCINDEXPOINTCLOUDINDEX /
183PEPEDIT / Edits polylines and 3D polygon meshes.
184PLPLINE / Creates a 2D polyline.
185POPOINT / Creates a point object.
186POFFHIDEPALETTES / Hides currently displayed palettes (including the command line).
187POLPOLYGON / Creates an equilateral closed polyline.
188PONSHOWPALETTES / Restores the display of hidden palettes.
189PREPREVIEW / Displays the drawing as it will be plotted.
190PRINTPLOT / Plots a drawing to a plotter, printer, or file.
191PSPSPACE / Switches from a model space viewport to paper space.
192PSOLIDPOLYSOLID / Creates a 3D wall-like polysolid.
193PTWPUBLISHTOWEB / Creates HTML pages that include images of selected drawings.
194PUPURGE / Removes unused items, such as block definitions and layers, from the drawing.
195PYRPYRAMID / Creates a 3D solid pyramid.

Command Shortcuts – Q

Sr.NumberTitle
196QCQUICKCALC / Opens the QuickCalc calculator.
197QCUIQUICKCUI / Displays the Customize User Interface Editor in a collapsed state.
198QPQUICKPROPERTIES / Displays open drawings and layouts in a drawing in preview images.
199QVDQVDRAWING / QVLAYOUTCLOSE
200QVDCQVDRAWINGCLOSE / Closes preview images of open drawings and layouts in a drawing.
201QVLQVLAYOUT / Displays preview images of model space and layouts in a drawing.

Command Shortcuts – R

Sr.NumberTitle
202RREDRAW / Refreshes the display in the current viewport.
203RAREDRAWALL / Refreshes the display in all viewports.
204RCRENDERCROP / Renders a specified rectangular area, called a crop window, within a viewport.
205REREGEN / Regenerates the entire drawing from the current viewport.
206REAREGENALL / Regenerates the drawing and refreshes all viewports.
207RECRECTANG / Creates a rectangular polyline.
208REGREGION / Converts an object that encloses an area into a region object.
209RENRENAME / Changes the names assigned to items such as layers and dimension styles.
210REVREVOLVE / Creates a 3D solid or surface by sweeping a 2D object around an axis.
211ROROTATE / Rotates objects around a base point.
212RPRENDERPRESETS / Specifies render presets, reusable rendering parameters, for rendering an image.
213RPRRPREF / Displays or hides the Advanced Render Settings palette for access to advanced rendering settings.
214RRRENDER / Creates a photorealistic or realistically shaded image of a 3D solid or surface model.
215RWRENDERWIN / Displays the Render window without starting a rendering operation.

Command Shortcuts – S

Sr.NumberTitle
216SSTRETCH / Stretches objects crossed by a selection window or polygon.
217SCSCALE / Enlarges or reduces selected objects, keeping the proportions of the object the same after scaling.
218SCRSCRIPT / Executes a sequence of commands from a script file.
219SECSECTION / Uses the intersection of a plane and solids, surfaces, or mesh to create a region.
220SETSETVAR / Lists or changes the values of system variables.
221SHASHADEMODE / Starts the VSCURRENT command.
222SLSLICE / Creates new 3D solids and surfaces by slicing, or dividing, existing objects.
223SNSNAP / Restricts cursor movement to specified intervals.
224SOSOLID / Creates solid-filled triangles and quadrilaterals.
225SPSPELL / Checks spelling in a drawing.
226SPLSPLINE / Creates a smooth curve that passes through or near specified points.
227SPLANESECTIONPLANE / Creates a section object that acts as a cutting plane through 3D objects.
228SPLAYSEQUENCEPALY /
229SPLITMESHSPLIT / Splits a mesh face into two faces.
230SPESPLINEDIT / Edits a spline or spline-fit polyline.
231SSMSHEETSET / Opens the Sheet Set Manager.
232STSTYLE / Creates, modifies, or specifies text styles.
233STASTANDARDS / Manages the association of standards files with drawings.
234SUSUBTRACT / Combines selected 3D solids, surfaces, or 2D regions by subtraction.

Command Shortcuts – T

Sr.NumberTitle
235TMTEXT / Creates a multiline text object.
236TATABLET / Calibrates, configures, and turns on and off an attached digitizing tablet.
237TBTABLE / Creates an empty table object.
238TEDITTEXTEDIT / Edits a dimensional constraint, dimension, or text object.
239THTHICKNESS /
240TITILEMODE /
241TOTOOLBAR / Displays, hides, and customizes toolbars.
242TOLTOLERANCE /
243TORTORUS / Creates a donut-shaped 3D solid.
244TPTOOLPALETTES / Opens the Tool Palettes window.
245TRTRIM / Trims objects to meet the edges of other objects.
246TSTABLESTYLE / Creates, modifies, or specifies table styles.

Command Shortcuts – U

Sr.NumberTitle
247UCUCSMAN / Manages defined user coordinate systems.
248UNUNITS / Controls coordinate and angle display formats and precision.
249UNHIDEUNISOLATEOBJECTS /
250UNISOLATEUNISOLATEOBJECT /

Command Shortcuts – V

Sr.NumberTitle
251VVIEW / Saves and restores named views, camera views, layout views, and preset views.
252VGOVIEWGO / Restores a named view.
253VPDDVPOINT / Sets the 3D viewing direction.
254VPLAYVIEWPLAY / Plays the animation associated to a named view.
255VSVSCURRENT / Sets the visual style in the current viewport.
256VSMVISUALSTYLES / Creates and modifies visual styles and applies a visual style to a viewport.

Command Shortcuts – W

Sr.NumberTitle
257WWBLOCK / Writes objects or a block to a new drawing file.
258WEWEDGE / Creates a 3D solid wedge.
259WHEELNAVSWHEEL / Displays a wheel that contains a collection of view navigation tools.

Command Shortcuts – X

Sr.NumberTitle
260XEXPLODE / Breaks a compound object into its component objects.
261XAXATTACH / Inserts a DWG file as an external reference (xref).
262XBXBIND / Binds one or more definitions of named objects in an xref to the current drawing.
263XCXCLIP / Crops the display of a selected external reference or block reference to a specified boundary.
264XLXLINE / Creates a line of infinite length.
265XRXREF / Starts the EXTERNALREFERENCES command.

Command Shortcuts – Z

Sr.NumberTitle
266ZZOOM / Increases or decreases the magnification of the view in the current viewport.
267ZEBRAANALYSISZEBRA
